Moving the Seat Backward and

Forward

E162375

WARNING

Rock the seat backward and forward

after releasing the lever to make sure

that it is fully engaged.

Adjusting the Height of the

Driver's Seat

E70730

Recline Adjustment

E163872

116

C-MAX (CCG) Canada/United States of America, enUSA, First Printing

Seats
