Circuits protectedFuse ratingFuse
Horn.20AF36
SYNC module.
7.5AF37
GPS module.
Blower motor relay.
5AF38 Horn relay.
Windshield wiper relay.
Remote keyless entry.
7.5AF39
Rear heating, ventilation and air conditioning.
Trailer tow backup relay coil.
Park lamp relay coil.
Front blower motor.40AF40
Rear blower motor.40AF41
Heated rear window.40AF42
Trailer socket.
30AF43
Trailer tow module.
Auxiliary power points.60AF44
Trailer connectors B+ supply.
40AF45
Trailer tow module.
Power windows.30AF46
Cigar lighter socket.20AF47
Rear auxiliary power points.20AF48
Front auxiliary power points.20AF49
Ignition relay 1.60AF50
Not used.-F51
Modified vehicle connections.40AF52
Modified vehicle connections.40AF53
200
Transit (TTH) Canada/United States of America, enUSA, First Printing
Fuses
