Circuits protectedFuse ratingFuse
Central locking system 2.15AF1
Central locking system 1.15AF2
Ignition switch.15AF3
Parking assist control module.
5AF4
Brake transmission shift interlock.
Rain sensor module.5AF5
Windshield washer pump.15AF6
Not used.-F7
Not used.-F8
Right-hand high beam.10AF9
Left-hand high beam.10AF10
Right-hand exterior lamps.
25AF11
Left-hand position lamps.
Not used.-F12
On-board diagnostic.
15AF13
Battery saver.
Turn signal indicator.
25AF14 Power windows delayed accessory.
Lane departure sensor heated windshield pad.
Left-hand exterior lamps.
25AF15 Right-hand position lamps.
High mounted stoplamp.
Audio unit.
20AF16
Navigation unit.
Instrument panel cluster.
7.5AF17
Heater control.
Headlamp switch module.
10AF18 Steering wheel module.
Stoplamp switch supply.
205
Transit (TTH) Canada/United States of America, enUSA, First Printing
Fuses
