US Type Charger 48A Installation Manual Rev0.1
Ford Pro contact info: chargingsupport@fordpro.com and 1-800-34-FLEET
3.6 Holster Installation
1. Separate the holster from the hook.
Figure 3-13 Separate the holster
2. Fasten the hook on the wall with appropriate screws.
2-1. For finished walls supported by wood studs, use 2pcs screws (#12
tapping or M6 ) .
2-2. The recommend torque is 25 kgf.cm (21.7 lbf·in).
Figure 3-14 Secure the hook
