15
PEACH
™
2 / PEACH
™
2 go PEACH
™
2 Pro Max
REPETITION RATE 0.5 -1s 0.5 -1s
PULSE LENGTH Free discharge 3ms Free discharge 3ms
MAX OPTICAL OUTPUT 3.3-5.6 J/cm² 10.4 J/cm² *
WAVELENGTH 550 - 1100nm 550 - 1100nm
POWER LINE INPUT 100 - 240V, 50/60Hz 3A 100 - 240V, 50/60Hz 3A
OPERATING TEMPERATURE 5 Celsius to +40 Celsius 5 Celsius to +40 Celsius
OPERATING HUMIDITY 40% to 80% 40% to 80%
OPERATING PRESSURES 800 to 1,060 hPa 800 to 1,060 hPa
TREATMENT AREA (SPOT SIZE) 4.5 cm² 11.5 cm²
* in some countries the max optical output may be lower due to regulations.
TECHNICAL SPECIFICATIONS
PEACH
™
devices are filtered broadband Intense Pulsed Light systems with the following
technical specifications:
Below cable information is provided for EMC reference:
CABLE
MAX CABLE LENGTH,
SHIELDED / UNSHIELDED
NUMBER
CABLE
CLASSIFICATION
AC Power Line 1.5m, Unshielded 1 Set AC Power
