20
PHENOMENON
BASIC EMC
STANDARD
IMMUNITY TEST LEVELS
HOME HEALTHCARE ENVIRONMENT
Electrical fast transient/burst IEC 61000-4-4
±1 kV
100kHz repetition frequency
Conducted disturbances
induced by RF fields
IEC 61000-4-6
3V, 0.15MHz-80MHz
6V in ISM bands and amateur radio bands
between 0.15MHz and 80MHz
80%AM at 1kHz
PHENOMENON
BASIC EMC
STANDARD
IMMUNITY TEST LEVELS
HOME HEALTHCARE ENVIRONMENT
Electrostatic Discharge IEC 61000-4-2
±8 kV contact
±2kV, ±4kV, ±8kV, ±15kV air
Conducted disturbances
induced by RF fields
IEC 61000-4-6
3V, 0.15MHz-80MHz
6V in ISM bands and amateur radio bands
between 0.15MHz and 80MHz
80%AM at 1kHz
Table 6: Signal Input /Output Parts Port
Table 7: PATIENT coupling PORT
TRANSPORT CONDITIONS:
If the device has been stored at temperatures outside of the stated operating range, then
please allow at least 30 minutes before use to allow the device to acclimatize.
TEMPERATURE -10 Celsius to +50 Celsius
HUMIDITY 30% to 80%
PRESSURES 500hPa to 1,060hPa
