PHENOMENON
BASIC EMC
STANDARD
IMMUNITY TEST LEVELS
HOME HEALTHCARE ENVIRONMENT
Electrical fast transient/burst IEC 61000-4-4
±2 kV
100kHz repetition frequency
Surges
Line-to-line
IEC 61000-4-5 ±0.5 kV, ±1 kV
Surges
Line-to-ground
IEC 61000-4-5 ±0.5 kV, ±1 kV, ±2 kV
Conducted disturbances
induced by RF fields
IEC 61000-4-6
3V, 0.15MHz-80MHz
6V in ISM bands and amateur radio bands
between 0.15MHz and 80MHz
80%AM at 1kHz
Voltage dips IEC 61000-4-11
0% U T ; 1 cycle
and
70% U T ; 25/30 cycles
Single phase: at 0º
Voltage interruptions IEC 61000-4-11 0% U T; 250/300 cycles
FREQUENCIES TEST LEVEL [A/M] MODULATION
30 kHz 8 CW
134,2 kHz 65 Pulse modulation 2,1 kHz
12,56 MHz 7.5 Pulse modulation 50 kHz
Table 4: Proximity magnetic fields
Table 5: Input AC Power Port
