Forest-Master FM9DD - Parts List

Forest Master Models: FM9DD/FM14DD/FM18DD 23
Parts List
PART NAME QTY. PART NAME QTY.
1 BASE 1 50 ISO 4034-M10-NUT 4
2 WHEEL 2 51 ISO 4015 - M8 x 30 x 28-N 1
3 AXLE 1 52 ISO 4015 – 5/16-24 x 300 x 30-N 1
4 20mm WASHER 2 53 drum end cap 1
5 BASE RUBBER FOOT 2 54 ISO 4015 - M8 x 15 x 15-N 4
6 BACK PLATE 1 55 ISO 4015 - M8 x 20 x 6-N 4
7 UNF 5/16 – 24 x 0.75 Bolt 4
56 Battery Box 1
8 PETROL ENGINE 1
57 Battery 1
9 DRUM HOUSING 1
58 M6x125 Bolts 2
10 FIXED BLADE 1
59 ISO 10511-M6-NUT 2
11 ISO 4162 - M8 x 12 x 12-N 3
12 DRUM HOUSING OUTER PLATE 1
FM9DD Parts 56 – 59 are not fitted
13 1
14 Circlip for Bores DIN 472 – 47x2 1
FM9DD & FM14DD
15 HOPPER OPEN MICRO SWITCH 1
NO. PART NAME QTY.
16 HOPPER RUBBER GASKET 1 11 ISO 4162 - M8 x 12 x 12-N 2
17 DRUM 1 19 M10x25-25 SHALLOW HEAD BOLT 8
18 ROTATING BLADE 2 38 Coach Bolt M12x285 3
19 M10x25-25 SHALLOW HEAD BOLT 10 52 ISO 4015 -5/16-24 x 250 x 30-N 1
20 ISO 7045 – M4 x 14 - Z - 14N 2
21 HOPPER 1
22 HOPPER TRAY 1
23 RUBBER FINGERS 1
24 1
25 HOPPER GUARD CLAMP PLATE 1
26 HOPPER GUARD PP PLATE 1
27 ISO 4015 - M6 x 20 x 18-N 5
28 Washer ISO 7089 - 6 19
29 ISO 10511-M6-NUT 15
30 EMERGENCY STOP SWITCH 1
31 DRUM SPACER SLEEVE 1
32 ISO 4015 - M8 x 16 x 8-N 7
33 10
34 LOWER BLANKING PLATE 1
35 1
36 DISCHARGE CHUTE 1
37 ISO 4015 - M6 x 12 x 12-N 4
38 Coach Bolt M12x330 3
39 Serrated Washer M12x0.5 3
40 3
41 ISO 4034-M12-NUT 3
42 ISO 4015 - M6 x 16 x 16-N 6
43 Split Pin 2mm x 25mm 2
44 Dome Axle Cap 2
45 Washer ISO 7089 - 8 13
46 ISO 10511-M8-NUT 11
47 Washer ISO 7089 - 10 8
48 ISO 4015 - M10 x 45 x 26-N 4
49 4
ITEM
NO.
ITEM
NO.
Radial Ball Bearing_SKF 6005
25x47x12
HOPPER GUARD MOUNTING
BRACKET
DIN 6905-7.4-FSt M8 SPRING
WASHER
DISCHARGE CHUTE DIRECTION
FLAP
DIN 6905-11-FSt
DIN 6905-9.3-FSt M10 SPRING
WASHER
