Table of Content
Safety 3
Introduction and initial assembly 6
Transportation / Positioning 7
Noise Emissions 7
Machine Storage 7
General Arrangement 8
Mechanical Specifications 8
Machine Arrangement 8
Electrical Specifications 8
Machine Footprint 10
Operating Procedure 11
Initial Requirements 450DT 12
Main Menu 13
450DT Basic Operation 13
450DT Settings 15
450DT Saving Parameters to Memory 16
450DT Loading Previously Saved Parameters from Memory 16
Operating Techniques 17
Optional Extras and Accessories 17
Reducing Windows - Fitting (optional) 19
Trolley - Self Assembly Instructions (optional) 20
Reel Feed - Self Assembly Instructions (optional) 22
Tooling 23
450DT Standard Baseboard 24
450DT Reducing Window Baseboard 24
Plastics 25
Post Forming Operations 26
After Forming 26
Trimming 26
Warranty 27
Seals 27
Heating Elements 27
Vacuum System 27
Service / Repair 28
Replacing Seals 28
Replacing a Heating Element 29
Electrical Troubleshooting 31
Vacuum / Pressure Troubleshooting 32
Replacing the Filter 34
Cleaning 35
Lubrication 35
Wiring Diagram Formech 450DT 36
Spare Parts Listing 38
EC Machinery Directive 40
