Put the hook into the slot of the outer door, for the positioning.
3
Fix the decoration door onto the outer door by screws and bolts.4
You’ll need:
Phillips screwdriver
D
1/4 in. and 5/16 in.
Nut driver
Screws D
ST3.5 x 45 (4)
Screws C
ST3.5 x 25 (2)
Screws B
ST4 x 14 (8)
Top Hook
Mounting Seats (2)
Brackets (2)
10
ATTENTON: you need an assistant to hold the top of the machine to prevent it forward.
