fortessa FTDEV1P - 6 Setup; DIP Switches Settings of Doorstation; DIP Switches Settings of Monitor

-10-
6.Setup
6.2 DIP Switches Settings of Monitor
6.1 DIP Switches Settings of Doorstation
installation.
Bit state Descriptions
ID = 1(01), set to the second Door Station.
ID = 2(10), set to the third Door Station.
ID = 3(11), set to the fourth Door Station.
1
2
ON
1 2
ON
1 2
ON
1 2
ON
There are 6 bit switches in total. The DIP switches are used to configure the User Code for each
Monitor.
ON(1)
=
OFF(0)
=
ON ON
Bit-6 is used to set video impedance,it should be set to ON if the Monitor is in the end of the line(bus),
otherwise set to OFF.
Bit state Setting Bit state Setting
si rotinom ehT
not at the end
of the bus.
The monitor
is at the end
of the bus.
1 2 3 4 5 6
ON
1 2 3 4 5 6
ON
Important Note:
Please remove the plastic film of the monitor before use.
