LED Lights 27
LED Activity and Meaning
Changing LED Appearance
If user wants to change the appearance of the LEDS, follow these steps:
1. From the controller, click Configuration > Devices > AP, and then select the AP.
2. Select one of these settings for the LED Mode setting:
• Normal: LEDs are as described above
• Blink: Sets all LEDs flashing; this is useful to locate an AP
• Dark: Turns off all LEDs
3. Click OK.
TABLE 4: LED Activity and Meaning
LED COLOR STATE MEANING
Status No Color — No power.
Either there is no power or the LEDs are set to Off on the con-
troller. Check the LED setting on the controller by clicking
Configuration > Devices > AP, selecting the AP and then
checking the setting for LED Mode.
CYAN ON AP starting, stage 1.
GREEN Blinking AP starting, stage 2.
GREEN/
WHITE
Alternating AP is discovering the controller.
GREEN/BLUE Alternating AP is downloading configuration from the controller.
BLUE Blinking slowly AP is online and enabled.
BLUE Blinking rapidly AP is online and enabled.
Some activity on one or both radios.
RED/YELLOW Alternating AP Failure.
For details, check the controller for alarms by clicking Monitor
> Alarms > Pending Alarms.
BLUE/YEL-
LOW
Alternating AP is online and enabled.
One or both radios are either scanning or an admin has shut-
down the radios.
