16 17
For Models FS-108F-POE, FS-108F-POE
For Model FS-108F
Plug in your device to a power outlet using the provided power cables.
Note: We recommend connecting your FortiSwitch to an uninterruptible power
supply (UPS) in case of a power outage
Basic Connections
Power Outlet
or UPS
Power Connection
Supplied Power Cable
Power Outlet
or UPS
Power Connection
Supplied Power Cable and Adapter
Installation
Desktop Option
1. Place the unit on a flat, clean and stable surface
2. Ensure there is at least 1.5in of clearance for adequate airflow
3. Plug the provided power cables into the rear of the unit and then into a
grounded electrical outlet or separate power source
1.5in
1.5in1.5in
1.5in
To Next Page
