Fortis RC-400A - Page 8

8
77
Power wire
x1
102
Magnetic board axle
x1
78
L/R
Chain cover L/R x2
103 Magnetic board x1
79
Crank hole cap
x2
104
Screw ST ST3 x 10 x Φ5.6
x5
80
Shaft Ring d17
x1
105
Tension spring
x1
81
washer
x1
106
Magnet seat 45.5 x 130 x 10.5
x1
82
Bearing 6203-2RS
x2
107
Square magnet 39 x 24.5 x 10
x4
83
Bushing Φ22 x Φ17.1 x 5.5
x1
108
Hex boltM6 x 45 x S10
x1
84
Hex bolt 16mm
x4
109
Nut M6 x H5 x S10
x2
85
Middle Axle
x1
110
Resistance motor
x1
86
Nylon nut M6 x H6 x S10
x4
111
Screw ST4.2 x 16 x Φ8
x4
87
Belt plate
x1
112
Sensor seat
x1
88
Magnet
φ
Φ15 x 7
x1
113 Speed sensor x1
89
Belt
x1
114
Tension wire
x1
90
Tension spring Φ2.0 x Φ12 x
79 x N27
x1
115
Cap φ25 x 22
x2
91
Nylon nut M8 x H7.5 x S13
x1
116
Bearing 6001-2RS
x2
92
Idle wheel bracket
x1
117
Bearing bracket
x2
93
Wave washerd12 x Φ17 x 0.3
x1
118
Bearing plate
x2
94
Bearing 6001-2RS
x2
119
Bolt M6 x 8 x S10
x2
95
Idler wheel
Ф
39 x
Ф
34 x 24
x1
120 Bolt M6 x 10 x S10 x5
97
Screw M8 x 12 x Φ10 x 5 x
S12
x1
121 Flywheel Axle x1
98 Hex bolt 16mm x2
122
L/R
Crank x2
99
Washer d6
x2
123
Nut M10 x 1.25 x H7.5 x S14
x2
100
Washer d6 x Φ12 x 1.2
x2
124
Crank cover
x2
101
Screw ST4.2 x 19 x Φ8
x1
