83
Network
Ethernet
One 10/100Mbps RJ45 port
Wireless Standard
IEEE 802.11b / g / n
Data Rate
IEEE802.11b: 11Mbps (Max.);
IEEE802.11g: 54Mbps (Max.);
IEEE802.11n: 150Mbps (Max.).
Frequency bands
2412-2472MHz
Maximum power
18dBm
Wireless Security
WEP, WPA, WPA2
Remote Access
P2P DDNS
Network Protocol
IP, TCP, UDP, HTTP, HTTPS, SMTP, FTP, DHCP, DDNS,
UPnP, RTSP, ONVIF
System
Requirements
Operating System
Microsoft Windows 2000/XP, Vista 7, 8;
Mac OS
Browser
Microsoft IE8 and above version or compatible browser;
Mozilla Firefox;
Google Chrome;
Apple Safari.
Other Features
Motion Detection
Alarm via E-mail, upload alarm snapshot to FTP
User Accounts
Three levels user role
Firewall
Supports IP Filtering
Reset
Reset button is available
Power
Power Supply
DC 12V / 1.0A
Power Consumption
4.2 Watts (Max.)
Physical
Dimension (L * W * H)
153mm * 92mm * 86mm / 6.0in * 3.6in * 3.4in
Net Weight
380g / 0.8lb
Environment
Operating
Temperature
-20ºC ~ 60ºC (-4ºF ~ 140ºF)
Operating Humidity
10% ~ 80% non-condensing
Storage Temperature
-20ºC ~ 60ºC (-4ºF ~ 140ºF)
Storage Humidity
0% ~ 90% non-condensing
Certification
IC, CE, FCC, RoHS
ITEMS
FI9803EP
Image Sensor
Sensor
High Definition Color CMOS Sensor
Display Resolution
1280 * 720 (1.0 Megapixels)
Min. Illumination
0 Lux (with IR Illuminator)
Lens
Lens Type
Glass Lens
focal length
f: 4mm (option 2.8mm,6mm,8mm)
Aperture
F1.2
Angle of View
Horizontal:70º
Diagonal :75º
Image Compression
H.264
Image Frame Rate
30fps (60Hz), 25fps (50Hz), downward adjustable
