Foscam FI9903P - Page 89

85
Diagonal: 75º
Video
Image Compression
H.264
Image Frame Rate
30fps (60Hz), 25fps (50Hz), downward adjustable
Resolution
1080P (1920 * 1080), 720P (1280 * 720), VGA (640 *
480), QVGA (320 * 240)
Stream
dual stream
Image adjustment
The hue, brightness, contrast, saturation, sharpness are
adjustable
Flip image
flip and mirror
Infrared mode
Automatic or manual
IR range
With 2 Infrared Lamp Array, IR LEDs for IR range up to
30m / 98ft
Network
Ethernet
One 10/100Mbps RJ45 port
Remote Access
P2P DDNS
Network Protocol
IP, TCP, UDP, HTTP, HTTPS, SMTP, FTP, DHCP, DDNS,
UPnP, RTSP, ONVIF
System
Requirements
Operating System
Microsoft Windows 2000/XP, Vista 7, 8;
Mac OS
Browser
Microsoft IE8 and above version or compatible browser;
Mozilla Firefox;
Google Chrome;
Apple Safari.
Other Features
Motion Detection
Alarm via E-mail, upload alarm snapshot to FTP
Privacy Block
Set privacy area manually
User Accounts
Three levels user role
Firewall
Supports IP Filtering
Reset
Reset button is available
Power
Power Supply
DC 12V / 1.0A
Power Consumption
4.2 Watts (Max.)
Physical
Dimension (L * W * H)
153mm * 92mm * 86mm / 6.0in * 3.6in * 3.4in
Net Weight
380g / 0.8lb
Power Consumption
<14 Watts
Environment
Operating
Temperature
-20ºC ~ 60ºC (-4ºF ~ 140ºF)
Operating Humidity
10% ~ 80% non-condensing
Storage Temperature
-20ºC ~ 60ºC (-4ºF ~ 140ºF)
Storage Humidity
0% ~ 90% non-condensing
Certification
CE, FCC, IP66, RoHS
ITEMS
FI9804W
Image Sensor
Sensor
High Definition Color CMOS Sensor
Display Resolution
1280 * 720 (1.0 Megapixels)
Min. Illumination
0 Lux (with IR Illuminator)
