92
ITEMS
FI9800P
Image Sensor
Sensor
High Definition Color CMOS Sensor
Display Resolution
1080 * 720 (1.0M Pixels)
Min. Illumination
0 Lux (With IR Illuminator)
Lens
Lens Type
Glass Lens
focal length
f:2.8mm
Aperture
F1.2
Angle of View
Horizontal: 70º
Diagonal: 75º
Video
Image Compression
H.264
Image Frame Rate
23fps (1280 * 720)
Resolution
720P (1280 * 720), VGA (640 * 480), QVGA (320 * 240)
Stream
dual stream
Image adjustment
The hue, brightness, contrast, saturation, sharpness are
adjustable
Flip image
flip and mirror
Infrared mode
Automatic or manual
IR range
With 30pcs IR-LED, IR LEDs for IR range up to 20m / 66ft
Audio
Input / Output
External RCA interface for two-way audio
Audio Compression
PCM / G.726
Network
Ethernet
One 10/100Mbps RJ45 port
Wireless Standard
IEEE 802.11b / g / n
Data Rate
IEEE802.11b: 11Mbps (Max.);
IEEE802.11g: 54Mbps (Max.);
IEEE802.11n: 150Mbps (Max.).
Frequency bands
2412-2472MHz
Maximum power
18dBm
Wireless Security
WEP, WPA, WPA2
Remote Access
P2P DDNS
Network Protocol
IP, TCP, UDP, HTTP, HTTPS, SMTP, FTP, DHCP, DDNS,
UPnP, RTSP, ONVIF
System
Requirements
Operating System
Microsoft Windows 2000/XP, Vista 7,8;
Mac OS
Browser
Microsoft IE8 and above version or compatible browser;
Mozilla Firefox;
Google Chrome;
Apple Safari.
Other Features
Motion Detection
Alarm via E-mail, upload alarm snapshot to FTP
Privacy Block
Set privacy area manually
User Accounts
Three levels user role
Firewall
Supports IP Filtering
Reset
Reset button is available
Power Supply
DC 12V / 1.0A
