Parameter Settings
INTEGRAL REMOTE
Mnemonic Default Single Section High Temperature Solid Door Single Section High Temperature Solid Door (Pass Through) Single Section High Temperature Glass Door Single Section Meat Temperature Solid Door Single Section Low Temperature Solid Door Single Section Fish Temperature Solid Door Single Section Dual Temperature Solid Door (Top Section) Single Section Dual Temperature Solid Door (Bottom Section) Double Section High Temperature Cabinet Solid Door Double Section High Temperature Cabinet Glass Door Double Section Meat Temperature Cabinet Solid Door Double Section Low Temperature Cabinet Solid Door Single Section High Temperature Solid Door Single Section Low Temperature Solid Door Double Section High Temperature Cabinet Solid Door Double Section High Temperature Cabinet Glass Door Double Section Low Temperature Cabinet Solid Door
MDL HYS HYS HYS HYS HYS HYS HYS HYS HYS HYS HYS HYS HYS HYS HYS HYS HYS HYS
SPL -2 1 1 1 -2 -21 -2 1 -23 1 1 -2 -21 1 -21 1 1 -21
SPH 10 5 5 5 5 -15 5 5 -15 5 5 5 -15 5 -15 5 5 -15
SP 3.5 2 2 2 -2 -21 -1 2 -23 2 2 -2 -21 2 -21 2 2 -21
HY0 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3
HY1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
CMD 30 5 5 5 5 5 5 5 5 5 5 5 5 0 5 5 5 5
CRT 90 180 180 180 180 180 180 180 180 180 180 60 60 0 0 0 0 0
CT1 4 4 4 4 5 5 4 4 5 4 4 5 5 4 5 4 4 5
CT2 7 6 6 7 5 5 7 6 5 6 7 5 5 6 5 6 6 5
PB 7 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5
IT 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100
DT 0 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6
CT 10 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5
AR 75 70 70 70 70 70 70 70 70 70 70 70 70 70 70 70 70 70
CMS 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100
CRS 35 90 90 90 90 90 90 90 90 90 90 90 90 90 90 90 90 90
CRD 15 10 10 10 10 10 10 10 10 10 10 10 10 10 10 10 10 10
CDS 50 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60
CFF 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60
60
CSS 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60
CSO 1 12 12 12 12 12 12 12 12 12 12 12 12 12 12 12 12 12
CST 60 30 30 30 30 30 30 30 30 30 30 30 30 30 30 30 30 30
DFM TAD TIM TIM TIM TIM TIM NON TIM TIM TIM TIM TIM TIM TIM TIM TIM TIM TIM
DFT 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6
DSP -12 -12 -12 -12 -12 -12 -12 -12 -12 -12 -12 -12 -12 -12 -12 -12 -12 -12
DST 4 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15 15
DMI 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2
DLI 10 10 10 6 15 15 6 10 15 10 10 15 15 10 15 6 10 15
DTO 20 15 15 15 20 20 15 15 20 15 15 20 20 15 20 15 15 20
DTY OFF OFF OFF OFF GAS GAS OFF OFF GAS OFF OFF GAS GAS OFF ELE OFF OFF ELE
DSY OFF OFF OFF OFF HI HI OFF OFF HI OFF OFF HI HI OFF HI OFF OFF HI
SOD 10 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5
DPD 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
DRN 60 0 0 0 90 90 0 0 90 0 0 90 90 0 90 0 0 90
