25.2
TRACK
IN
SOLO
BUTTON
(2
TRK
IN
SOLO
1,
2)
This
is
pressed
to
monitor
the
master
recorder
output
connected
to
the
2
TRK
IN
jacks
1
and
2
(42).
When
this
button
is
pressed,
the
LED
above
it
will
be
lit
and,
as
for
other
SOLO
buttons,
the
input
signal
from
the
2
TRK
IN
jack
(42)
corresponding
to
the
button
number
(1
or
2)
that
is
pressed,
can
be
monitored
via
the
PFL
buss.
Also,
if
one
of
either
button
is
pressed,
the
meter
L,
R
section
will
indicate
the
mixed
signal
of
the
PFL
buss
and
thus
may
be
used
to
confirm
the
output
level
of
the
master
recorder
that
is
connected.
This
function
is
effective
only
on
the
monitor
system
as
in
(24).
26.
MONITOR
SELECTOR
(MONITOR
SELECT)
Selects
the
signal
to
be
sent
to
the
MONITOR
OUT
jacks
1
-
2
(45)
and
PHONES
jack
(47).
STEREO:
Signals
(STEREO
buss
output
signals)
output
from
the
STEREO
OUT
jacks
1
and
2
(43)
can
be
monitored.
CUE
:
Signals
(CUE
buss
output
signals)
output
from
the
CUE
OUT
jacks
(46)
can
be
monitored.
Down
position
is
ON
and
up
position
is
OFF
for
these
buttons.
Also,
please
note
that
these
two
buttons
are
the
LOCK
RELEASE
type
(only
one
of
either
button
can
be
pressed).
27.
MONITOR
OUT
SELECTOR
(MONITOR
OUT)
This
is
for
selecting
whether
1
(RCA
pin
jack)
or
2
(stereo
phone
jack)
of
the
MONITOR
OUT
jack
(45)
is
to
be
active.
As
both
1
and
2
are
at
the
same
level
(-10dBV)
and
same
impedance
(10KQ
load),
the
selection
depends
on
the
connector.
MONITOR
OUT
Select
f
Q
1
*
=
^
>
O
O
l=£>
|*£j>
t0f
|
I
©
I
Large
monitor
speaker
either
one
\
M0
*
0
UT
1
,—
T
—,
l
»-»
2
l=£>
©
I-[>
|
M
a
t
^p°
r
|
<=>
[O]
Small
monitor
speaker
Example
28.
MONITOR
LEVEL
KNOB
(MONITOR)
Adjusts
the
output
level
of
the
signal
output
from
MONITOR
OUT
jacks
1
and
2
(45).
29.
HEADPHONE
LEVEL
KNOB
(PHONES)
Adjusts
sound
level
of
the
headphones
plugged
into
the
PHONES
jack
(47).
30.
PREFADER
LISTEN/SOLO
LEVEL
KNOB
(PFUSOLO)
Adjusts
the
master
level
of
the
PFL
buss.
The
total
sound
volume
can
be
set
at
solo
monitoring
by
pressing
the
PFL
button
(15)
or
SOLO
button.
31.
CUE
MASTER
LEVEL
KNOB
(CUE
MASTER)
The
CUE
buss
master
level
adjusting
knob.
Output
level
at
the
CUE
OUT
jack
(46)
can
be
set.
This
is
convenient
for
setting
the
total
sound
volume
when
sending
to
the
CUE
buss
the
signals
of
SUB
MIX
sections
3
and
4
by
the
CUE/L-R
selector
(5).
Please
note
that
when
at
least
one
PFL
button
(15)
or
SOLO
button
is
pressed,
the
L
and
R
meters
will
indicate
the
mixed
signal
level
on
the
PFL
buss.
33.
X
L
R
INPUT
JACKS
These
are
XLR
type
balanced
input
connectos
(#3
pin
hot)
which
match
signals
from
mic
levels
to
line
levels.
They
can
also
match
unbalanced
type
input
signals
but
then
pins
#1
and
#2
must
be
GND
and
the
PHANTOM
POWER
switch
(35)
must
be
switched
OFF
at
all
times.
If
a
plug
is
inserted
into
the
phone
INPUT
jack
(34),
that
jack
will
have
priority
and
the
signals
to
the
XLR
connector
will
be
by-passed.
34.
P
H
O
N
E
INPUT
JACKS
(INPUT)
These
are
unbalanced
phone
jacks
which
signals
from
mic
levels
to
line
levels.
They
can,
of
course,
match
the
balanced
line
type
input
signals
but
then
the
plug
tip
must
be
hot
and
the
ring
cold.
35.
PHANTOM
POWER
SWITCH
(
+
48V)
The
ON/OFF
switch
for
the
DC48V
phantom
power
to
the
microphone.
This
must
always
be
switched
OFF
(button
up
position)
when
a
dynamic
microphone
is
used
because
it
does
not
require
a
power
supply.
When
this
is
switched
ON,
pin
#
1
will
be
0
volt
and
DC48
volts
will
be
applied
to
pins
#2
and
#3.
36.
TAPE
INPUT
JACKS
(TAPE)
Normally,
the
outputs
(unbalanced)
of
a
multitrack
recorder
are
plugged
in
here.
These
are
set
for
the
rated
input
level
of
-
lOdBV
(20K0)
before
leaving
the
production
line
(Refer
to
NOTE
1
of
the
P.O.).
37.
ACCESSORY
SEND/RECEIVE
JACKS
(SEND/RCV)
These
jacks
are
used
for
plugging
in
external
sound
processors
such
as
digital
reverbs,
compressors/
limiters
and
noise
gates.
These
are
in
stereo
phone
format
(TIP
is
send,
RING
is
receive)
and
when
nothing
is
plugged
in
here,
the
signal
will
be
jumpered
from
send
to
receive.
GND
insert
[
|_
RING
TIP
GNO
(Connected
to
TIP
|
u
To
effector
(SEND)
—
From
effector
(RECEIVE)
T\_
GND
I
Connected
to
RING~1
38.
D
I
R
E
CT
OUT
JACK
(D.
OUT)
The
output
jacks
of
the
post
fader
(post
equalizer)
signals
of
each
channel.
These
can
be
used
for
sends
to
the
effect
unit.
32.12
POINT
LED
BARGRAPH
METERS
These
indicates
the
output
levels,
from
left
to
right,
at
the
GROUP
OUT
jacks
1,
2,
3,
4
(40)
and
the
STEREO
OUT
jack
1
(43)
L,
R.
39.
A
U
X
OUT
JACKS
(AUX
OUT
1,
2,
3,
4)
Output
jacks
of
the
AUX
buss
1
~
4.
Used
for
sending
the
mixed
signal
of
the
AUX
1
~
4
send
(8)
to
the
digital
reverb.
