SECTION 7, OTHER METHODS OF OPERATION
A wide variety of controlling from sound reinforcement
by the main speaker to monger sends to lire stage and
effect processing are possible when This mi war is used
as & PA system mixer in smaN auditoriums and clubs.
In the example of Fig. 11 n the outputs of the musical in¬
struments are grouped ?nto (A) and {BJ. then sent bo the
main speakers through 1h@ GROUP TO STEREO sections
(20) and (21). AUX 3, 4 sends (0) are used for sends
to the processor and AUX 1, 2 sends (8} are used for
2 channel stage monitor sends (PRE/POST selector (9)
PRE). In addition, mixed signals of CD, cassette deck,
effect outputs, etc. are sent by patching the CUE OUT
jack (46) to the GROUP buss 1, 2 and mixed into group
(A). The main speaker sound volume is adjusted by the
STEREO master fader (22), and total sound volume of
the monitor send, by the AUX master GAIN 1 and 2 (23).
