D-108 Owner’s Manual (MIDI Implementation Chart/MMC List)
Fostex System Exclusive Message
General Structure=F0 51<device id><sub id 1>(<data>)F7
* Numbers are all expressed in hexadecimal units.
Table: <sub id 1> (<data>)
Command or Model Set Acknowledge or Status
Controller to D-108 D-108 to Controller
Loop on/off 12 22 (<on/off>)
Post locate 12 28 (<post locate mode>)
Auto rec 12 2D (<on/off>) 32 2D (<edit message>)
Lock enable 12 41 (<lock enable>)
Lock mode 12 42 (<lock mode>)
Copy clip 12 45 (<count><mmc track>) 32 45 (<edit message>)
12 46 (<count=01><repeat count>)
Copy paste or 32 46 (<edit message>)
12 46 (<count><repeat count><mmc track>)
Erase 12 47 (<count><mmc track>) 32 47 (<edit message>)
Clipboard play 12 49 32 49 (<edit message><mmc track>)
Undo 12 4A 32 4A (<edit message>)
Redo 12 4B 32 4B (<edit message>)
Move clip 12 4D (<count><mmc track>) 32 4D (<edit message>)
12 4E (<count=01><repeat count>)
Move paste or 32 4E (<edit message>)
12 4E (<count><repeat count><mmc track>)
Move clip 12 4D (<count><mmc track>) 32 4D (<edit message>)
Move clip 12 4D (<count><mmc track>) 32 4D (<edit message>)
Move clip 12 4D (<count><mmc track>) 32 4D (<edit message>)
Move clip 12 4D (<count><mmc track>) 32 4D (<edit message>)
Digital in ch. 13 41 (<channel><channel>)
Digital out ch. 13 42 (<channel><channel>) * Refer to Note.
Move clip 12 4D (<count><mmc track>) 32 4D (<edit message>)
Program change 13 43 (<program>)
Click on/off 13 44 (<on/off>)
Resolution on/off 13 46 (<on/off>)
Midi Sync out 13 47 (<nidi sync>)
MTC offset mode 13 48 (<MTC offset mode>)
13 49 (<count=3><on/off><vari pitch>)
Vari pitch or
13 49 (<count=1><on/off>)
Signature set 14 01 (<signature map>) 34 00 (<edit message>)
Tempo set 14 02 (<tempo set map>) 34 00 (<edit message>)
Tempo map all erase14 03 34 00 (<edit message>)
Preroll time set 14 04 (<mmc time>)
Frame rate set 14 06 (<frame rate>)
Fs rate set 14 07 (<fs rate>)
Time base set 14 08 (<time base>)
<Note><Note>
<Note><Note>
<Note>
Following protocol is effective only in equipment which will reply by -
Identity Reply=F0 7E<channel>06 02 51 01 00 0D 00 01 ** ** ** F7 (D-108)
against the Inquiry Message=F0 7E<channel>06 01.
Fostex MIDI System Exclusive Message Format for D-108
