D-108 Owner’s Manual (MIDI Implementation Chart/MMC List)
<signature map><signature map>
<signature map><signature map>
<signature map> bar2, bar1, bar0, sign, sigd
bar2: The 100th digit of the bar figure is expressed in BCD.
bar1: The 10th digit of the bar figure is expressed in BCD.
bar0: The 1 digit of the bar figure is expressed in BCD.
sign: Numerator of the signature to be set is expressed in BCD.
sigd: Denominator of the signature to be set is expressed in BCD.
When specified as sign=00 and sigd=00, signature data of that bar position will be
deleted. Also, bar2=bar1=bar0=sign=sigd=00 indicates "no corresponding data"
(such as when a figure specified by <event number> do not exist at receiving the
signature map request).
<tempo set map><tempo set map>
<tempo set map><tempo set map>
<tempo set map> bar2, bar1, bar0, beat, tmp2, tmp1, tmp0
bar2: The 100th digit of the bar figure is expressed in BCD.
bar1: The 10th digit of the bar figure is expressed in BCD.
bar0: The 1 digit of the bar figure is expressed in BCD.
beat: The beat figure is expressed in BCD.
tmp2: Numerator of the tempo to be set is expressed in BCD.
tmp1: Denominator of the tempo to be set is expressed in BCD.
tmp0: The 1 digit of the tempo is expressed in BCD.
When specified as tmp2=tmp1=tmp0=00, tempo data of that bar and meter position
will be deleted. Also, bar2=bar1=bar0=sign=sigd=00 indicates "no corresponding
data" (such as when a figure specified by <event number> do not exist at receiving
the signature map request).
<event number><event number>
<event number><event number>
<event number> When one data registered by <signature map> and <tempo set map> is declared as
one event, the number of events from head of the tune (the umpteenth event
counted from head of the tune) must be specified. <event number="00"> is the first
event.
<midi sync><midi sync>
<midi sync><midi sync>
<midi sync> 00: OFF
01: MIDI CLOCK
02: MTC
This corresponds to "MIDI SYNC OUT" of the SETUP menu.
<vari pitch><vari pitch>
<vari pitch><vari pitch>
<vari pitch> Will be composed of two bytes (Q, P).
Q: 0qqqqqqq (binary) -> <vari data> = "qqqqqqqppppppp" A 14 bit data of X0.1
P: 0qqqqqqq (binary) attached with a minus symbol.
Vari-pitch must be specified, at +0.1% when MSB (q)=0 (Example: 0000000000001),
and at -0.1% when MSB (q)=1 (Example: 1111111111111).
<frame rate><frame rate>
<frame rate><frame rate>
<frame rate> 00: 30nd
03: 25
04: 24
05: 30df
Corresponds to selecting "FRAME" of the SETUP menu.
<fs rate><fs rate>
<fs rate><fs rate>
<fs rate> 00: 48kHz
01: 44.1kHz
Corresponds to selecting "FS SET" of the SETUP menu.
<MTC offset mode><MTC offset mode>
<MTC offset mode><MTC offset mode>
<MTC offset mode> 00: ABS
01: signature
Corresponds to selecting "MTC OFFSET MODE" of the SETUP menu.
<time base><time base>
<time base><time base>
<time base> 00: ABS
01: BAR BEAT
02: MTC
Corresponds to selecting "TIME BASE SEL" of the SETUP menu.
<level data><level data>
<level data><level data>
<level data> t1, t2 ...... tn
n: Indicates the track number.
tn: Indicates absolute 8 bits of the Audio 16 bit data (Range: 00~7F).
