D-108 Owner’s Manual (MIDI Synchronization)
86
Setting the D-108 (Master)
1.The D-108 will output the MTC for the sync operation.
Set the “MIDI sync output signal setting” in the Setup mode to “MTC.”
# Refer to “MIDI sync output signal setting” in the Setup mode on page "112" for the procedure and additional information.
2.Set any frame rate for the “MTC Frame rate setting” in the Setup mode.
# Refer to “MTC Frame rate setting” in the Setup mode on page "113" for the procedure and additional information.
3. Select “ABS” for the sake of compatibility with the FD-8 for “MTC offset mode setting” in the Setup mode.
# Refer to “MTC offset mode setting” in the Setup mode on page "114" for the procedure and additional information.
4.Set an offset time for “MTC offset time setting” in the Setup mode.
# Refer to “MTC offset time setting” in the Setup mode on page "113" for the procedure and additional information.
5.Set the “MIDI device ID setting” in the Setup mode to “00”.
# Refer to “MIDI device ID setting” in the Setup mode on page "120" for the procedure and additional information.
6.Select “SP DIF” as the digital output signal for the “Digital output track setting” in the Setup mode.
* Only an S/P DIF digital signal can be used with the D-80, D-80 Ver. 2, DMT-8 Ver. 2, DMT-8 VL, and DMT-8.
# Refer to “Digital output track setting” in the Setup mode on page "119" for the procedure and additional information.
7.Press the DISP SEL key while holding down the EXECUTE/YES key to select MTC as the Time Base indication.
Setting the FD-8 (Slave)
# Refer to the FD-8 User’s Guide for the procedure and additional information.
1.Use the same frame rate as the D-108 for the “MTC frame rate setting” in the Setup mode.
2.Use the D-108’s offset time for the “MTC offset time setting” in the Setup mode.
There is no “MTC offset mode setting” on the D-80, D-80 Ver. 2, DMT-8 Ver. 2, and DMT-8 VL. When you use the D-108’s
setting, the MTC offset mode will automatically become “ABS.”
3.Set the “MIDI device ID setting” in Setup mode to “01” on the FD-8.
4.Set the Slave mode to “On” for the “Slave mode setting” in the Setup mode.
You can set the Slave mode on the D-80, D-80 Ver. 2, DMT-8 Ver. 2, and DMT-8 VL, but you cannot select a sync signal (SLAVE
TYPE). If you use the D-108’s setting, “SP DIF” will be automatically selected.
5.Press the DISP SEL key while holding down the EXECUTE/YES key to select MTC as the Time Base indication.
<Note>
After this setting, check the following items on the FD-8.
* “SLAVE” is flashing on the display: When the Chase Lock operation is complete, this indicator will light.
* “DIGITAL” lights on the display: The FD-8 is syncing to the external digital signal.
<Note>
Do not connect or remove the optical cable the DATA IN connector while Slave mode is on. This can generate noise, affecting the connected
qexternal devices.
