Foundations 4141079 - Parking Brake Operation; Front Wheel Swivel Lock Operation

Parking Brake Operation.
To lock parking brake:
1. Pressdownonparkingbrakelockbaronthe
    rearaxleassemblyintolockedposition(Fig. 1).

2. Checkthatwheelsarelocked.
To unlock parking brake:
1. Placetoeunderparkingbrakelock
    barandliftupintounlockedposition
   (Fig. 2).
Fig. 1
Fig. 2
Parking
Brake
Lock Bar
WARNING
Front Wheel Swivel Lock Operation.
To lock Wheel Assembly:
 1.Rotatefrontwheelassemblyuntilitispointing
Forward.(Fig. 1).

2.Pushdownswivellockuntilitsnapsinplace.
 3.Checkthatfrontswivelissecurelylockedby

pushingsidetosideonfrontwheelassembly.
4.Repeatsteps1through3forotherwheelAssembly.
• Always use front wheel swivel locks when pushing stroller on
uneven ground.
WARNING
AB20049_G10
Fig. 1
13
• Always lock parking brake when stroller is stopped and when
loading and unloading children.
