Foundations 4141079 - Canopy Removal

8
To remove canopy:
1.  Opensidesofcanopyaroundstrollerhandleby
 pullingfabrichook&loopfastenersapart(1)
 (Fig. 1).
2.  Pullrearpanelofcanopyupandoutofopening
 betweenstrollerhandleandhandlesupport(2).
3.  Removecanopyfromrearsupporttubeby
 releasinghook&loopfasteners.
4.  Removescrew,retainer,andcanopystrap
fromhandle.(Fig. 2)

5.  Removerearcanopytube(shorttube)by
pressingretainertabin(1)andslidingrear
canopytubeup(2)(Fig. 3).
6.  Repeatstep5foroppositesideofstroller.
7.  Removemaincanopytube(longtube)bypressing
 retainertabin(1)andslidingmaincanopytubeup
 (2)(Fig. 3).
8.  Repeatstep7foroppositesideofstroller.
Fig. 3
Retainer Tab
2
1
Fig. 1
1
2
1
STEP 6 - Canopy Removal
Stroller
Handle
Fig. 2
Canopy
Strap
