Foundations 4141079 - Rear Axle and Brake Assembly; Rear Wheel Assembly

STEP 1 - Rear Axle and Brake Assembly
1. LayfoldedStroller Frame Assembly (A)on
 cleanoorwithhandletube(1)ontopandfront
 footrests(2)contactingoor(Fig. 1).
2. AssembleRear Axle Tube Assembly (C)
 tostroller(Fig. 2).
  - PositionRearAxleTubeAssembly(C)withbrake
   tube(3)upandopenendofrearaxle
   assembliestowardrearlegs.
  - Sliderearaxletubeassembly(C)ontothe
   lowerendsofrearlegs(4)untilcontacting
   springpins.Pressspringpinsandslide
   rearaxleassembly(C)ontorearleg(4)until
   springpinssnapintoholesinrearaxle
   tubeassembly(C).
  - PullonRearAxleTubeAssembly(C) tocheck
thatitissecuredontorearlegs.
Fig. 2
Fig. 1
Style May Vary
STEP 2 - Rear Wheel Assembly
1. AlignholeinrearaxlerodofRear Wheel With Axle B with
 holesinRearAxleTubeAssembly(C).Sliderearwheelwith
axleBintoRearAxleTubeAssembly(C)(Fig. 1).
2. SlideRear Wheel With Axle (B)inuntilholeinrear
 axlerod1alignswithholeinrearaxletube.
3. InsertM6 x 34 mm Screw (H) throughRearAxleTube
 Assembly(C)andrearaxleroduntilscrewcomesoutbottomof
 RearAxleTubeAssembly(C)(Fig. 2).
 NOTE:Ifendofscrewdoesnotslideintohole,check
  alignmentofholeinaxle.Ifholeinaxleisnot
  aligned,removerearwheelandstartover.
4. InsertM6 Nut (I) into6-sidedrecessonbottomof
 rearaxletubeandusingphillipsscrewdriver,secure
 Screw(H)byturningintonutuntiltight(Fig. 3).
 Repeatsteps2thru4foroppositerearwheel.
Fig. 1
Fig. 2
Fig. 3
5
1
2
2
3
C
4
1
B
H
H
I
C
