Foundations 4141079 - Canopy Assembly

7
STEP 5 - Canopy Assembly
To attach canopy:
1.Positioncanopywithroundedfrontsectionontop
andplacecanopyinrearseatareaandovertop
offrontseats.
2.SecureMain Canopy Tube(longtube)bypushing
endofMain Canopy TubeintoCanopy Retainerslot
locatedonoutsideofhandlenearthearmrest(Fig. 1).
3.
SecureshortRear Canopy Tube(shorttube)bypushing
endofCanopy TubeintoCanopy Retainer slot
locatedonoutsideofthehandlenearthetopofthe
backseat(Fig. 2).
Repeatsteps2and3tosecurecanopytubesonother
sideofstroller.
4.Securebackofcanopy.
Securecanopysidesaroundstrollerhandleby
securinghook&loopfastenersoneachside(Fig. 3).
Repeatonothersideofcanopy.
Fig. 2
Rear
Canopy
Tube
Canopy
Retainer
Handle
Fig. 3
Fig. 1
Main
Canopy
Tube
Canopy
Retainer
Armrest
5. AttachRearCover.
Withtheloopsideoffabricfastenerfacingoutwards,aligncut
outinthecenteroftheRearCoverwiththecentertubeofthe
strollerhandle.Pressthehookandloopfabricfastening
togetheronbothsidesofthecentertube.

Wrapeachsideofthebackcoveraroundthesidehandletube
andpresstogethertheloopsideoftheRearCovertotheHook
sideoftheMainCanopy.(Fig. 4) 

Fig. 4
