Fox 180 User Manual

 
32
ABOUT YOUR FOX BOAT
Thank you for purchasing a Fox boat. If cared for properly you should get many years of pleasure out of it. These boats can
be inated and assembled in about 30mins, making trips from the car to the water practical without the need for a trailer and
perfect for shing sessions. This manual will help you to familiarise yourself with the boat and help you to keep it in the best
possible condition. Keep this manual onboard in a dry area. Should you sell the boat make sure to provide the new owner
with the manual.
BOAT SPECIFICATION
Model Floor
Length
(cm)
Width
(cm)
Chambers
Tube
(cm)
Persons
Max Load
(kg)
Power (hp)
Weight
(kg)
Fox 180 Green Slat 180 124 2 32 1 150 2.5
Fox 180 Camo Slat 180 124 2 32 1 150 2.5
Fox 200 Green Slat 200 129 2 35 1 200 3.3 25
Fox 200 Camo Slat 200 129 2 35 1 200 3.3 27
Fox 240 Green Airdeck 240 154 3 38 2 240 5 32
Fox 240 Camo Airdeck 240 154 3 38 2 240 5 34
Fox 290 Green Airdeck 290 154 3+1+1 38 4 510 10 40
Fox 290 Camo Airdeck 290 154 3+1+1 38 4 510 10 57
Fox 290 Green Aluminium 290 154 3+1+1 38 4 510 10 40
Fox 290 Camo Aluminium 290 154 3+1+1 38 4 510 10 57
Fox 320 Green Airdeck 320 162 3+1+1 41 4.5 560 15 50
Fox 320 Camo Airdeck 320 162 3+1 41 4.5 560 15 64
Fox 320 Green Aluminium 320 162 3+1 41 4.5 560 15 68
Fox 320 Camo Aluminium 320 162 3+1 41 4.5 560 15 68
YOUR BOAT AND THE ENVIRONMENT
• The environment is fragile, please use your boat with the utmost respect for the environment.
• Avoid exceeding the noise threshold and producing excessive fuel vapours.
• Your boat generates waves and noise that can be detrimental to the natural environment.
• Respect local boating laws and regulations.
SAFETY INSTRUCTIONS
• Read the instructions carefully.
• Not for use in the sea.
• Carefully read the instruction manual provided with your choice of outboard engine should you choose to use one.
• It is the responsibility of the boat operator to learn and know the laws applicable to a boat and abide by them regarding how
it is to be equipped and operated.
• The applicable laws and regulations in force may change and differ according to the following factors:
- the location where the boat is commissioned
- the requirements of the local authorities
- the type of use of the boat
- the time of day
- the operating conditions
- the size, speed, route, type of boat (power, oars, etc.)
- the navigation mode
• All passengers onboard must wear appropriate clothing and have a life jacket.
• Make sure that the boat’s standard equipment (oars, air pump and repair kit) is on board. Survival equipment other than the
mandatory items is sometimes necessary.
• An individual under the inuence of drugs or alcohol is not in a condition to pilot a boat.
• Do not exceed the maximum load rating and the maximum engine power indicated on the boats manufacturers plate.
• Special attention should be given to wind and tides, as their variation has certain effect on fuel consumption.
• If you plan to navigate in unfamiliar waters, consult with those familiar with the area concerning possible hazards
and dangers.
• Always report your time and point of departure, your route and your estimated time of return to someone on shore.
• Do not navigate in the dark or in hazardous conditions if correct navigation lighting has not been installed.
• Do not use a compressed air source to inate the boat. Over ination may cause the seams and/or walls to rupture.
• Whether oars or a small outboard motor is used depends on conditions. The power may not be enough to counter tidal
currents, small channels or shallow water.
• Respect the maximum power ratings! An excessively powerful motor may cause dangerous manoeuvrability and stability
difculties with serious consequences.
• Equip your outboard engine with an emergency kill-switch cord. This switch will stop the engine if the operator should pull
the cord, for any reason whatsoever.
• Regularly check that the engine is securely fastened. Loose screws may make the craft uncontrollable, or result in the
engine becoming unattached!
NAVIGATION WARNINGS
• All passengers must be seated inside the boat and must be able to hold onto one or two hand holds. Do not sit on
the oaters.
• Outboard engines are dangerous. Rough handling of your tender may lead to serious injury or death. Never equip a boat
with an engine for which it is not adapted. Stay clear of swimmers and do not allow them to approach the rear of the boat
when the engine is running.
• Avoid rapid accelerations which may cause passengers to fall overboard.
• Weight must be evenly distributed. Do not accelerate suddenly if your boat is motorised and not heavily laden. A poorly
controlled boat may result in stability and manoeuvring problems.
• Avoid sand banks and shallow water or approach with extreme caution.
• If one of the oaters become punctured while underway, shift the load of the boat to the opposite side. Try to limit the leak
with your hand or a strap and head for the nearest shore as quickly as possible.
• Do not allow children to drive the boat unsupervised by adults.
• Always bring your oars along snapped in place.
DOCKING
• Do not use the engine when landing on the beach.
• Avoid sharp objects when coming to dock or shore.
• Do not drag the boat over rocks, sand, shingles or tarred surfaces.
• Always carry the boat.
• Cover the boat when leaving it in the sun out of the water for long periods of time.
• If leaving the boat on a beach leave part of the boat in the water to cool the boat and avoid oater overpressure.
• It is not recommended that you tow the boat the front ring is for mooring or securing an anchor line to only.
FOOTPUMP
WARNING:
• Do not use a compressed air source to inate the boat. Over ination may cause the seams and/or walls to rupture.
• Use the specially designed pump to inate your boat.
• The Foot Pump can deliver the air pressure needed to fully inate your boat. To inate, insert the hose into the “outlet” hole
on the pump. We rmly recommend you always carry your foot pump on board for safety.
• Before undertaking a long trip, inate the boat for a full 24 hours to be sure all chambers are completely airtight.
CAUTION:
Before boarding, always check the boat is adequately inated.
