Fox 180 User Manual

 
76
see bubbles forming, check your valve seating and base and be sure the valve insert is screwed tight. If you continue to have
problems it’s probably time to order new valves. Replacement of the whole valve can be done with a simple tool that comes
with the replacement valve.
2. Finding punctures
If the boat is losing air, and all the valves are good you probably have a small puncture. Small punctures can be repaired
easily and permanently. Spray around inside and outside of the hull until air bubbles mark the position of the leak. If you have
no luck nding a slow leak with air bubbles, inate the boat to maximum air pressure and try to listen to nd the leak. If you
can narrow the area down, return with a spray bottle to identify the source of the leak. Making small repairs. Punctures less
than 3mm / 1/8”in size can be repaired simply without a patch. Deate your boat, then clean and dry area to be repaired.
Apply a small drop of glue to cover the puncture, and let dry 12 hours. If you need to get on the water sooner, let dry 30
minutes and then inate the boat, inating the compartment with the repair only 3/4 full. This repair might not be permanent
so add a drop again at a late date to make it permanent.
3. Rips or Tears
Your Boats come with a repair kit as standard equipment. If you no longer have your repair kit, you can order a new one
from your dealer. Cut a piece of repair material large enough to overlap the damaged area by approximately 12mm / 1/2”,
and round off the edges. Apply our glue to the under side of patch and around the area to be repaired. Too much glue will
interfere with a proper repair. Allow adhesive to become tacky for 2-4 minutes, and then place patch on the damaged area.
Use a weight to apply 3-5 lbs. of pressure for 12 hours. After patch has dried, apply glue around the edges for a complete
seal (dry 4 hours).
4. Large and Difcult Repairs
If you have a difcult repair, contact customer services and we will advise you on the best way to x your boat.
5. If you see water coming into the boat, check the following:
- Is the drain valve open?
- Is the diaphragm in the drain valve working properly?
- Has it rained recently?
- Is there a hole in the oor?
Warranty Registration
You can register a warranty for this product online at the Fox website - www.foxint.com. Log in or create an account to start
the registration process. You will need the product code, date of purchase and place of purchase to complete the registration.
After registration make a note of your Customer Reference code to view warranty details via your Fox website account.
The warranty does not cover the following:
• Over ination of tubes no more than 0.25bar/3.63psi
• Over ination of the air deck no more than 1.00bar/14.5psi.
• Air loss due to temperature differences
• Air loss through the pressure valve in hot conditions
• Folding marks. This is normal, and these will disappear during use.
• Glue residue. All Fox boats are handmade and the occasional glue mark may be visible.
• Small imperfections on glued parts, which do not affect the usability.
• Low air loss within 48 hours (up to 20% air loss in comparison to operating pressure).
• Damage caused by the use of solvents of any kind
• Damage caused by battery acid, oil and fuel.
• Damage caused by nail polish, suntan lotion / oil.
• Damage caused by insect repellent.
• Damage caused by improper use.
• Damage caused by high pressure cleaning.
• Damage caused by the use of aggressive cleaning agents.
• Damage caused by incorrect assembly and disassembly of the boat.
• Damage caused by improper storage, poor ventilation.
2000mm
2400mm
380mm
350mm
320mm
1800mm
2900mm
900mm
860mm
1620mm
1660mm
690mm
1390mm
600mm
1240mm
900mm
3200mm
1720mm
410mm
380mm
• Damage caused by inadequate cleaning and maintenance of the boat.
• Damage in transit.
• Damage caused by use of pressure compressors to inate or deate the boat.
• Damage due to normal wear and tear.
• Damage caused by use of force.
• Damage caused by animals on or in the boat.
• Damage caused by water in the tube interior.
• Damage to the hull as a result of carelessness, as well as external inuences.
• Damage caused by participation in racing events of any kind.
• Damage caused by use of non-approved accessories.
• Damage caused by exceeding the maximum acceptable power KW / HP as well as the permissible engine weight.
• Damage caused by exceeding the permissible payload, and the recommended number of people.
*Your statutory rights shall remain unaffected.
If you have a problem with your boat that is covered by the warranty you should proceed as follows:
1. Contact your place of purchase and explain the problem.
2. The retailer will need to send Fox a photograph and explanation of the problem along with proof of purchase.
3. We will conrm if the problem is covered by the warranty.
4. Once conrmed the retailer has to send a courier return request to Fox and we will arrange collection of the boat.
5. We will then review the boat and arrange repair or replacement accordingly.
