18. If a part of the machine is missing, damaged or defective, or if an electric part is not working correctly, turn the
machine off at the switch and disconnect the machine from the power. Replace any missing, damaged or
defective parts before restarting the machine.
19. KEEP THESE INSTRUCTIONS for future reference. Use them to teach any other users.
20. This machine is manufactured according to the relevant safety regulations. To avoid dangerous situations, repairs
and maintenance must be exclusively made by a qualified or competent person.
21. Disconnect the machine from the mains before cleaning it or performing any maintenance.
22. PLANE only wood boards.
SPECIFICATIONS
Motor : 1500W – 240V (2hp)
Block speed : 8000rpm
Blade size : 258 x 18.2 x 3.2mm
Max thicknessing width : 254mm
Max thicknessing height : 153mm
Max cutting depth per pass : 2.5mm
Feed rate : 8m/min.
Range of cutting depth : 7 - 153mm
Thicknesser table size : 295 x 254mm
Dust port diameter : 50mm
Dimensions (h x l x d) : 410 x 550 x 585mm
Max. cutting length : 1000mm
Weight : 29kg
