UNPACKING AND CLEANING
Your new thicknesser is packaged in a cardboard box. Unpack it carefully, taking care with the loose parts. Remove
the protective coating from all non-painted parts. This can be removed by means of a soft cloth moistened with WD40.
Do not use acetone, petroleum or paint thinner.
Note : if any parts are damaged or missing, do not connect the machine to the power and do not switch it on until the
missing/damaged parts are replaced.
Do not throw away the cardboard box until you are sure the machine is working correctly.
Loose Parts Bag
1. "C" Circlip 4 pieces
2. Knife setting guide 2 pieces
3. Knife setting gauge shaft 1 piece
4. Base lock screw 8mm x 50 (L) 4 pieces
5. Elevation knob lock screw 6mm x 15 (L) 1 piece
6. Cutterhead raising hand crank 1 piece
7. Allen wrenches 4, 5, 6mm
8. Screwdriver handle 1 piece
9. Screwdriver shank 1 piece
10. Open end wrench 8 x 10 1 piece
