15
WARNING
Do not start the bandsaw before fastening the machine, assembling and
adjusting the workbench, checking belt tension and safety devices. Only after
performing these tasks you can connect the saw to the power supply. Otherwise the
bandsaw could start suddenly and cause personal injuries.
This machine is delivered almost completely assembled. Before use you must:
I. Fix bandsaw’s base
II. Assemble the workbench
III. Assemble the fence’s rail
IV. Assemble the fence
V. Connect the dust collection device
I. Bandsaw fastening
The bandsaw can be fastened to a surface or assembled on the four legs that are included in
the package. If you want to fix it on a surface:
1. Drill 4 holes on the surface on which you want to fix the bandsaw, while taking into
consideration the base of machine.
2. Use 4 locking devices suitable with the surface and fix the saw.
If you want to use the legs and the bars included in the package, put the machine on its side
and:
1. Assemble the 4 legs to bandsaw’s blade with 8 screws and the corresponding nuts and
washers.
2. Assemble the 8 bars with the screws and the washers.
3. Straighten up the bandsaw.
4. Firmly tighten all the screws.
5. Assemble the two wheels on the two left legs, to make the transport easier.
II. Workbench assembly FIG.2
A. Horizontal adjustment of the workbench
1. Raise the protective cap completely.
2. Check saw blade’s tension and adjust it if it is loose.
3. Loosen the lock screw (37).
4. By using a square, place the workbench at a right angle with the blade and
tighten the locking screw firmly (37).
III. Assembly of fence’s rail FIG.3
Fix fence’s rail (40) on the workbench with 4 wing screws and with washers.
