605-01-3 67 11
Fig. 14: Tie rod end link. Fig. 15: Sway bar end link.
17. Reinstall the tie rod end link (Fig. 14) and sway bar end link (Fig. 15). Torque all hardware to OEM
specification. Secure the tie rod end link’s castle nut with a new cotter pin.
18. Reinstall the wheels and torque to OEM specifications.
19. Set the vehicle back on the ground and drive back and forth several feet to allow the suspension to
settle. Now measure ride height and adjust if necessary. READ INSTALLATION GUIDELINES ON HOW TO
PROPERLY ADJUST PRELOAD.
20. Check that the suspension has proper clearance by steering completely in both directions.
21. Measure the vehicle’s ride height and adjust if necessary.
22. It is highly recommended your wheel alignment is checked.
CHECK AND FINAL DETAILS
