Step and Feed value
E.g.: Step value=10 means moving
distance is 10mm. Feed value=2000
means 2000mm/min
Spindle ON/OFF and control the spindle
speed. You can manipulate the slider to
reduce or increase the RPM. This is used
only when manually switching on the
spindle, not when running a G code
program.
Open G-code file
3D preview interface,
hold the
left mouse button, can
rotate
Angle, scroll the mouse
wheel, can be enlarged,
or reduced.
If you cannot see
anything, you need to
change to a computer
with support for
OpenGL2.0 graphics cards.
Send G-code file
Coordinate display
Status display
Common operation button, the mouse
icon on the above shows the specific
function
Command input box
Send command
Manual operation Direction buttons
Grblcontrol (Candle) Working Interface Introduction
Pattern size
-24-
