Foxconn 915G7MC - Product Introduction

5
Chapter 1 Product Introduction
Layout
15.Clear CMOS Jumper
16.Front Panel Connector
17.Serial ATA Connectors
18.FAN1 Connector
19.WOL Header (optional)
20.IrDA Header (optional)
21.USB Headers
22.1394 Connector (optional)
23.COM2 Header
24.PCI Expansion Slots
25.Front Audio Connector
26.SPDIF Out Connector (optional)
27.AUX_IN Connector (optional)
28.CD_IN Connector
11
1
2
3
4
5
6
7
8
9
13
1012
15
14
16
17
18
19
20
25
26
27
21
22
23
24
28
1.4-pin ATX_12V Power Connector
2.PCI Express x16 Slot (optional)
3.LGA775 CPU Socket
4.North Bridge: 915G/P/GV/GL Chipset
5.CPU Fan Connector
6.DIMM Slots (optional)
7.South Bridge: ICH6/ICH6R Chipset
8.24-pin ATX Power Connector
9.FDD Connector
10.ATA 100/66/33 IDE connector
11.BIOS Write-Protection Jumper (optional)
12.Chassis Intruder Header
13.BIOS TBL Jumper (optional)
14.Speaker Connector (optional)
