Integrated Peripherals

► OnBoard PCI IDE Controller

This item is used to enable or disable the IED controller.

► OnChip SATA Channel

[Disabled] : Disable SATA controller.

[Enabled] : Enable SATA controller.

► OnChip SATA Type

This item is used to set the operating mode of your SATA ports.

Options : [Native IDE]; [RAID]; [Legacy IDE]; [IDE -> AHCI].

[Native IDE] - This congures the SATA ports to support native IDE mode.

[RAID] - When you enable RAID, it means all your SATA drives must also support AHCI.

[Legacy IDE] - This congures the SATA ports to support legacy IDE mode which is running

for old Windows system .

[IDE -> AHCI] - The Advanced Host Controller Interface (AHCI) specication describes the

level interface for a Host Controller for Serial ATA. The specication includes a description of

the hardware/software interface between system software and the host controller hardware.

AHCI provides more advanced features including SATA features, but some SATA drives may

not support AHCI, unless they are labeled with AHCI support in its specication.

If your motherboard supporting AHCI, and you have a SATA device, which also supports AHCI,

then you can select IDE option to have fair performance (only PATA, SATA level), or you can

select AHCI to get its best performance.

► OnBoard Devices / USB Configuration / SuperIO Configuration

Press <Enter> to go to relative submenu.

Integrated Peripherals

OnBoard PCI IDE Controller Help Item

OnChip SATA Channel [Enabled]

OnChip SATA Type

[Native IDE] DISABLED: disables the

► OnBoard Devices

[Press Enter] integrated IDE

► USB Conguration [Press Enter] Controller .

► SuperIO Conguration [Press Enter]

PRIMARY : enableds only

the Primary IDE

Controller.

↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help

F9:Optimized Defaults

[Enabled]

Foxconn A6GMV Series User Manual
