"Memory Speed Adjust".
► Memory Speed Adjust
This item will appear only when the "Memory Speed Mode" is set to [Limit] or [Manual].
The available settings are: [800MHz], [1067MHz], [1333MHz], [1600MHz], [Auto].
► Current DRAM Speed
This item displays the current DRAM speed.
► GFX Engine Clock Override
This item allows you to enable/disable GFX Engine Clock Override support.
► PCI Express Clock
This option is used to adjust the speed of PCI Express slot. It may enhance the graphics card
speed.
► Spread Spectrum
If you enabled this function, it can signicantly reduce the EMI (Electromagnetic Interference)
generated by the system, so to comply with FCC regulation. But if overclocking is activated,
you had better disable it.
Voltage Options
► Memory Voltage Control
This option is used to change the DRAM voltage in a step of 50mV. The voltage can be incre-
mented from +50mV to +150mV.
► CPU Voltage Control
This option is used to change the CPU voltage in a step of 25mV. The voltage can be incre-
mented from +25mV to +375mV.
► NB Voltage Control
This item is used to adjust North Bridge(NB) voltage.
Adjusting the voltage beyond the NB
default voltage could result in damage to NB.
The default option is “Disabled”.
CMOS Setup Utility - Copyright (C) 1985-2006, American Megatrends, Inc.
Voltage Options
Memory Voltage Control [Disabled] Help Item
Current DRAM Voltage :1.596V
CPU Voltage Control [Disabled]
Current CPU Voltage :1.344V Disabled
+50mV
NB Voltage Control [Disabled] +100mV
+150mV
↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help
F9:Optimized Defaults
[Disabled]
