4-2 Install SATA Hard Disks
1. Shut down your computer.
2. Install SATA hard disks into the drive bays.
3. Connect all the SATA power and SATA data cables.
4-3 RAID Conguration
This motherboard supports RAID 0, RAID 1 and RAID10 functions.
Hardware and software you may need here :
■ A oppy drive ■ A DVD-ROM drive
■ A oppy disk(Or USB disk for Vista) ■ A motherboard driver CD
■ Several SATA hard disks ■ Windows XP or Vista Install CD
RAID Enable in BIOS
1. Boot up your computer, enter the BIOS setup by pressing [Del] key during POST.
2. Set the “OnChip SATA Type” to "RAID".
3. Press [F10] to save the setting, then PC will reboot itself.
Option ROM Utility
When PC is rebooting, press [Ctrl-F] key during POST to enter the main menu of the Option ROM
Utility.
View Drive Assignment: To view the disk drive assignment status by pressing [1].
Dene LD: To Create RAID by pressing [2].
Delete LD: To Delete RAID by pressing [3].
Controller Conguration: To view the SATA controller conguration by pressing [4].
Exit: Press [Esc] to exit AMD Option ROM Utility.
Option ROM Utility (c) 2008 Advanced Micro Devices, Inc.
View Drive Assignment. . . . . . . [ 1 ]
Define LD . . . . . . . . . . . . . . . . . [ 2 ]
Delete LD . . . . . . . . . . . . . . . . . [ 3 ]
Controller Configuration . . . . . . [ 4 ]
[ Main Menu ]
Press 1..4 to Select Option [ESC] Exit
