IDE Conguration

► OnChip SATA Channel

[Disabled] : Disable SATA ports 1,2,3,4.

[Enabled] : Enable SATA ports 1,2,3,4.

► OnChip SATA Type

This item is used to set the operating mode of your SATA ports.

Options : [Native IDE]; [RAID]; [AHCI]; [Legacy IDE].

[Native IDE] - This congures the SATA ports to support native IDE mode.

[RAID] - When you enable RAID, it means all your SATA drives must also support AHCI.

[AHCI] - The Advanced Host Controller Interface (AHCI) specication describes the register

level interface for a Host Controller for Serial ATA. The specication includes a description of

the hardware/software interface between system software and the host controller hardware.

AHCI provides more advanced features including SATA features, but some SATA drives may

not support AHCI, unless they are labeled with AHCI support in its specication.

If your motherboard supporting AHCI, and you have a SATA device, which also supports AHCI,

then you can select IDE option to have fair performance (only PATA, SATA level), or you can

select AHCI to get its best performance.

[Legacy IDE] - This congures the SATA ports to support legacy IDE mode which is running

for old Windows system.

► SATA IDE Combined Mode

[Disabled] : Disable SATA 5 and ESATA.

[Enabled] : SATA 5 and ESATA are used to simulate two additional IDE ports.

IDE Conguration

Help Item

OnChip SATA Channel

Disabled

OnChip SATA Type [Native IDE] I Enabled

SATA IDE Combined Mode [Enabled]

↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help

F9:Optimized Defaults

[Enabled]

Foxconn A88GMV Series User Manual
