Foxconn G41M Series User Manual

16
2
16
Audio Connector : CD_IN
CD_IN is a Sony standard audio connector, it can
be connected to a CD/DVD-ROM drive through a
CD/DVD audio cable.
Audio Connector : F_AUDIO
The audio connector supports HD Audio standard. It
provides the Front Audio output choice.
S/PDIF OUT Connector : SPDIF_OUT
The connector is used for S/PDIF output.
TPM Connector : TPM
The TPM (Trusted Platform Module) provides the
ability to the PC to run applications more secure and
to make transactions and communication more trust-
worthy. To utilize this function, you should purchase
additional device and install it.
Speaker Connector : SPEAKER
The speaker connector is used to connect speaker
of the chassis.
SPDIF_OUT
+5V
EMPTY
SPDIF_OUT
GND
1
2
3
4
CD_IN
CD_L GND CD_R
1
PORT1_L
PORT1_R
PORT2_L
SENSE_SEND
SENSE1_RETURN
PRESENCE_J
EMPTY
SENSE2_RETURN
AUD_GND
1 2
109
F_AUDIO
PORT2_R
LCLK#
LFRAME#
LRESET#
LAD3
VDD
LAD0
SB3V
NC
GND
LPCPD#
GND
EMPTY
LAD2
NC
LAD1
GND
NC
SERIRQ
CLKRUN#
NC
1 2
19 20
TPM
NC
SPKJ
EMPTY
SPEAKER
SPKJ
1
2
3
4
