Foxconn H81MXV Series User Manual

PRODUCT INTRODUCTION
2
1-1 Product Specications
CPU Support Intel
®
4thGenerationCoreprocessors
Maxprocessorpowerupto84W
For the latest CPU information, please visit:
http://www.foxconnsupport.com/cpusupportlist.aspx
Chipset Intel
®
H81
Memory 2x240-pinDDR3/DDR3LSDRAMDIMMs
Support up to 16GB of system memory
DualchannelDDR31600/1333MHzarchitecture
Expansion Slots 1 x PCI Express X16 slot
-SupportPCIExpressGen25GT/sdatarate
1 x PCI Express X1 slot
-SupportPCIExpressGen25GT/sdatarate
Storage Intel
®
H81 chipset
-2xSATA2.0connectors(3Gb/sdatatransferrate)
-2xSATA3.0connectors(6Gb/sdatatransferrate)
LAN Realtek RTL8111F Giga LAN chip
Support10/100/1000Mbps
Audio RealtekALC662audiochip
-HighDenitionAudio
-2/4/5.1-channel
-Support Jack-Sensing function
USB Supportupto6xUSB2.0ports(2rearpanelports,2onboardUSB
headerssupporting4extraports)
SupportUSB2.0protocolupto480Mb/s
Supportupto2xUSB3.0ports(2rearpanelports)
SupportUSB3.0protocolupto5Gb/s
Internal
Connectors
1x24-PinATXpowerconnector
1x4-pinATX12Vpowerconnector
2xSATA3.0connectors
2xSATA2.0connectors
2xUSB2.0headers
1xCPUFANheader(4-pin)
1xSystemFANheader(4-pin)
1 x Front panel header
1 x Front audio header
1 x Speaker header
1 x Clear CMOS header
1 x ME header
1 x VDDR_SEL header
Back Panel
Connectors
1xPS/2Keyboardport
1xPS/2Mouseport
1 x VGA port
1 x COM port
2xUSB2.0ports
2xUSB3.0ports
1 x DVI-D port(H81MXV-D)
1 x HDMI port(H81MXV)

Foxconn H81MXV Series Specifications

General

Brand	Foxconn
Model	H81MXV Series
Category	Motherboard
Language	English
