4. The stripe block value is xed and not changeable.
Press [F7] to nish the setting. Press [Y] to clear disk data.
5. The screen displays a Spanned RAID array of 421.36GB, which is the total sizes of
these three hard disks. That is, 111.79+76.69+232.88= 421.36GB. We recommend
not setting it to bootable as it will be impossible to recover if crashed. You can then
press [Ctrl]+[X] keys to exit the setup program, and restart your PC.
MediaShield Utillity Apr 26 2007
- Dene a New Array -
RAID Mode: Mirrored Stripe Block: Optimal
Free Disks Array Disks
Port Disk Model Capacity Port Disk Model Capacity
[-›] Add
[‹-] Del
[ESC] Quit [F6] Back [F7] Finish [TAB] Navigate [↑↓] Select [ENTER] Popup
Optimal
1.0 WDC WD1200JD-9 111.79GB
1.1 Hitachi HDT725 232.88GB
2.0 HDS728080PLA38 76.69GB
Spanning
2.1 ST3320620AS 298.09GB
Clear disk data?
[Y] YES [N] NO
MediaShield BIOS Apr 26 2007
- Array List -
[Ctrl-X] Exit [↑↓] Select [B] Set Bootable [N] New Array [ENTER] Detail
Boot Status Vendor Array Size
No Healthy NVIDIA JBOD 421.36G
