5.3 Installation Space Required
5.4 Tools Required
• Manual wrench;
• Electric drill (drill bit set 8mm);
• Crimping pliers;
• Stripping pliers;
• Screwdriver.
5.5 Installation Steps
Step 1: Fix the bracket on the wall
-
Choose the place you want to install the inverter. Place the bracket on the wall and mark the position of the 3
holes from bracket.
-
Drill holes with electric drill, make sure the holes are at least 50mm deep, and then tighten the expansion
tubes.
