FoxESS H3-10.0-E - EPS Output; Efficiency and Protection

8
AC inrush current [A] 15A@0.5ms
Max. output fault current [A] 150A@0.5ms
Max. output overcurrent
protection [A]
45
THDI <3%@rated power
AC INPUT
Max. AC power [VA] 10000 12000 16000 16000 16000
Rated grid voltage
(AC voltage range) [V]
400V/230VAC;380V/220VAC,3L/N/PE
Rated grid frequency [Hz] 50 / 60,
±
5
Max. AC current [A] (Per phase) 15.2 18.2 24.2 24.2 24.2
AC inrush current [A] 15A@0.5ms
Power Factor 1(Adjustable from 0.8 leading to 0.8 lagging)
4.4 EPS Output
Model
H3-5.0-E
AC3-5.0-E
H3-6.0-E
AC3-6.0-E
H3-8.0-E
AC3-8.0-E
H3-10.0-E
AC3-10.0-E
H3-12.0-E
EPS OUTPUT (WITH BATTERY)
Max. apparent AC Power [VA] 5000 6000 8000 10000 12000
Peak apparent AC
Power [VA] (60s)
10000 12000 14000 15000 15000
Rated output voltage [V] 400V/230VAC; 3L/N/PE
Rated grid Frequency [Hz] 50/60 50/60 50/60 50/60 50/60
EPS Max current [A]
(Per phase)
15.2 18.2 21.2 22.7 22.7
Power Factor 1(Adjustable from 0.8 leading to 0.8 lagging)
Parallel operation Yes@max10 Pcs
Switch time <20ms
THDV <3%@rated power
4.5 Efficiency and Protection
Model
H3-5.0-E
AC3-5.0-E
H3-6.0-E
AC3-6.0-E
H3-8.0-E
AC3-8.0-E
H3-10.0-E
AC3-10.0-E
H3-12.0-E
EFFICIENCY
MPPT efficiency 99.90% 99.90% 99.90% 99.90% 99.90%
Max. Efficiency 97.80% 97.80% 98.00% 98.00% 98.00%
Euro-efficiency 97.20% 97.20% 97.30% 97.30% 97.30%
PROTECTION
