4. Technical Data
4.1 PV Input (For H3 Only)
Model H3-5.0-E H3-6.0-E H3-8.0-E H3-10.0-E H3-12.0-E
PV
Max. recommended DC power [W] 7500 9000 10400 13000 15000
Max. DC voltage [V] 1000 1000 1000 1000 1000
Nominal DC operating voltage [V] 720 720 720 720 720
Max. input current
(input A / input B) [A]
14 / 14 14 / 14 26 / 14 26 / 14 26 / 14
Max. short circuit current
(input A / input B) [A]
16 / 16 16 / 16 32 / 16 32 / 16 32 / 16
MPPT voltage range [V] 160-950 160-950 160-950 160-950 160-950
MPPT voltage range (full load) [V] 210-800 250-800 240-800 280-800 320-800
Start-up voltage [V] 160 160 160 160 160
No. of MPP trackers 2 2 2 2 2
Strings per MPP tracker 1+1 1+1 2+1 2+1 2+1
4.2 Battery
[1]Minimum operation battery voltage is 150V
4.3 AC Output/Input
Model
H3-5.0-E
AC3-5.0-E
H3-6.0-E
AC3-6.0-E
H3-8.0-E
AC3-8.0-E
H3-10.0-E
AC3-10.0-E
H3-12.0-E
AC OUTPUT
Nominal AC power [VA] 5000 6000 8000 10000 12000
Max. apparent AC power [VA] 5500 6600 8800 11000 13200
Rated grid voltage
(AC voltage range) [V]
400V/230VAC;380V/220VAC,3L/N/PE
Rated grid frequency [Hz] 50 / 60,
±
5
Max. AC current [A] (Per phase) 8.0 9.6 12.8 16.0 19.2
Power Factor 1(Adjustable from 0.8 leading to 0.8 lagging)
Export Control YES
Battery
H3-5.0-E
AC3-5.0-E
H3-6.0-E
AC3-6.0-E
H3-8.0-E
AC3-8.0-E
H3-10.0-E
AC3-10.0-E
H3-12.0-E
Battery Type Lithium battery
Battery voltage [V]
180-600[1]
Full AC load Battery voltage [V] 205 250 330 410 480
Max. Charge/ discharge current [A] 26.0
Communication interface CAN/RS485
