9
PV reverse polarity protection YES
Battery reverse protection YES
Anti-islanding protection YES
Output short protection YES
Leakage current protection YES
Insulation Resistor Detection YES
Over Voltage category III (AC side), II (DC side)
Reverse connect protection YES
Over-current protection
/Over-temperature protection
YES
AC/DC surge protection Type II
AFCI protection
※
optional
DC switch optional
String monitoring function
※
optional
Note: '※' is under development.
4.6 General Data
DIMENSION AND WEIGHT
Dimension (W/H/D) [mm] 449*519*198
Net Weight [kg] 28
Cooling Natural FAN cooling
Inverter topology Non-isolated
Communication interface
Meter, WiFi/GPRS/LAN (optional), DRM, USB, BMS(CAN&RS485),
RS485
LCD display Backlight 16*4 character
ENVIRONMENT LIMIT
Installation wall-mounted
Ingress protection IP65 (for outdoor use)
Inverter operating temperature
range [°C]
-25…... +60 (derating at +45°C)
Storage/Operation relative humidity 0%-100% (without condensation)
Altitude [m] <2000
Protective class I
Storage temperature [°C] -40…… +70
Standby consumption [W] 15W
ldle mode YES
Button Capacitive touch sensor *4
Buzzer 1, inside (EPS & Earth fault)
