Foxtech S-RTK100 User Manual

Indicator Description
Indicator Feature Definition
Light
Note
Red Green Blue Yellow
GNSS
Locate
Search Satellite Flash
Single Point Positioning
Pseudo-Range Positioning
Flash
Float-Point Positioning Flash
Absolute Point Positioning On
Base Station Mode On
Board Setting Succeeded
Flash
Slowly
Bluetooth
Bluet-
ooth
Preparing Flash
Initialized, disconnect On
Connected
On
4G
Com-
muni-
cate
Data Not Ready Flash
Read SIM Card Succeeded
Flash
4G Connected On
Differential Data Flash
Fast
Power Power
No SD Card Flash
USB Connected
On
Working Normal Flash
SD Card Writing Error
On
Power
4G
Bluetooth
GNSS
On
S-RTK100 User Manual
©2022 FOXTECH All Rights Reserved 6
