50
Smart Diagnostic & TPMS Scanner TS7000 User's Manual V1.0
To make record of live data
To save live data of current frame
To stop recording live data
Table 8-1 Live Data Screen Button Screen
3. Swipe the screen up and down to view additional information when
necessary.
4. To move a data line to the top of Data List screen, just tap the line to
select and then press the button To Top. To view data records or test
reports, and press the button History. To make records of live data, just
tab the button Record, and press Pause to stop recording at any time. To
save the data, tap the Save icon.
9.2.3.2 Custom List
Custom List menu lets you to minimize the number of PIDs on the data list
and focus on any suspicious or symptom-specific data parameters.
To create a custom data list:
1. Press Custom List from the menu to display all available parameters
from the selected control module.
2. The custom data stream selection screen displays. Tap the lines you
wish to select. The numbers showing on the right side indicates the order
of selection and the live data will show as this order.
Figure 9-17 Sample Custom List Selection Screen
3. To deselect an item, tap the line again. Alternatively, tap SELECT ALL or
Deselect ALL to select or deselect all items at once.
4. Press OK to complete the selection, and all selected items display.
