IL-C-DRW-A001/A003 - 17 - © Future Products Group
Setting Up cont.
REFRIGERATED CABINETS - INSTALLATION
The condensate drain outlet must be connected to a suitable drain. Exit holes
are provided underneath, and on either side of the cabinet.
A P-trap must be included in the piping, to prevent contaminated air from
entering the cabinet.
Remove all tapes, ties and packers, used to prevent movement during transit.
Power Supply
and Earthing
The cabinet is supplied with a mains cable and three-pin plug. If the cabinet is
to be hard wired, this must only be done by a suitably qualified person.
Before connecting to the power supply, check that the local supply is correct to
that shown on the rating plate, located on the rear of the cabinet.
The connection terminals are located
behind a removable panel.
WARNING-THIS APPLIANCE MUST BE
EARTHED/GROUNDED
If the cabinet is not connected by a plug and socket, but is hard wired to the
mains supply, a means of isolation must be provided.
If a plug and socket are used, they should still be accessible after the cabinet is
installed.
Mains Lead
REFRIGERATED CABINETS
-
INSTALLATION
If damaged, the mains lead must ONLY be replaced by a qualified service
person.
