FPI P36-3 Zero Clearance Direct Vent Gas Fireplace 37
5th Grate Tab
Rear Bracket
Front Brackets
Notch
02-55
02-50
02-54
5) Position Log 02-53 across the cutouts in
Logs 02-49 and 02-51 with the notch on the
left side of the log fitting into the 2nd grate
tab.
Cutouts
2nd Grate Tab
02-53
02-49
02-51
02-49
02-51
02-53
02-49
02-51
02-53
02-55
02-53
02-50
02-55
02-53
02-53
02-51
Notch
Bracket
Bracket
02-49
02-51
02-49
02-51
4) Place Log 02-51 on the front right side of
the burner. Push the back of the log against
the 2 brackets with the notch on the bottom
right side of the log fitting into the right side
of the grate.
6) Place the bottom left front edge of Log
02-55 against the rear bracket on the burner
tray and rest the log on the cutout on
Log 02-53.
7) Sit Log 02-50 on the front left side of the
burner. Push the back of the log against the
2 front brackets with the notch on the
bottom of the log fitting into the first grate
tab.
8) Position Log 02-54 across the cutouts in
Logs 02-51 and 02-53. The notch in the
bottom right end fitting against the 5th grate
tab.
INSTALLATION
